12 VDC

0 to 55 °C

30 to 95 %

Yes

20W

Micro SIM

Yes

Yes

Yes

Via Smartphone/PC

Permanent Fault Alarm (Yes)

Temporary Fault Alarm (Yes)

High Current Warning Alarm (Yes)

System Low Battery Alarm (Yes)

750 (g)

L=80 x W=80 x H=185 (mm)

Read Load Current (3 Phase, & Up to 3 Feeders on Same Pole)

Power Line Status (Permanent/Temporary/Normal)

Language: Khmer

Voice Instruction

Be able to Control Fault Indicators (Up to 9 (FI) Modules for 3 Feeders on Same Pole (Above, Middle and Below))

User Management

Fault Indicator Setting Group

Software Support (Support PC/Smart Grid System/ Android Application)

Support Google Map View

Model (SNV-308)

Manufacturing Standards (ANSI/IEEE495-1988; Q/GPW 436-2010)

Type of Installation (Overhead Line)

Rated Voltage (Rated Voltage)

Current Rating (up to 1,000 A)

Rating Frequency (50/60 Hz)

Fault Indicator (Permanent fault/Temporary fault)

Automatic Alarming of Fault (Permanent/Temporary)

Communication Rang with DRC-010 (≤50 (Line of Sight, Max to ≤100m) )

Two Battery in Side (Yes)

Li-Iron Rechargeable Battery for Working (Li-Ion, 3.2V 600mAh)

Li-Iron Battery for Back Up (Li-Ion, 3.6V 2200mAh)

Solar Panel Supply for Rechargeable Battery (Yes)

Self Power Charging From MV Line (Yes)

Battery Life ( 8 to 10)

Angle of Visibility (360 Flashing Insight)

Fault Flashing (Every 1 Second)

LED Indicator Fault (Flashing)

Sampling Accuracy ( I <10 (±1%), I >10 (±2%) )

Static Power Consumption (20 uA)

Auto Reset Time (1 to 48 (User-Selectable) Hour)

Identification of Fault Current Duration (≥40 ms)

Short Circuit Current (16 (2 Seconds) KA)

Protection Rating Level (IP67)

Operating Humidity (30 to 93 %)

Temperature (0 to 55 °C)

Weight (750g)

Controller Dimensions (L=80 x W=80 x H=185)
